Product Description
Fluke 525B Temperature/Pressure Calibrator
(item no. 4307765)
Product Overview
This temperature/pressure calibrator gives you a workhorse combination of high accuracy and broad functionality for temperature and pressure instrument calibration. Compact and economical, it has an interface for automated calibration, providing wide workload coverage in instrument shops and calibration labs, as well as in ATE applications.
Features
- Simulates and measures all ANSI thermocouples, as well as L and U types, and provides cold junction compensation to enable calibration of a wide variety of thermocouple instrumentation
- Direct input for storage of ITS-90 RTD constants
- RTD source uncertainties to 0.03°C
- Extend pressure measurement range with any 750P and 700P Series Pressure Modules
- Converts easily to any pressure unit directly from the front panel or through remote communications
- Sources dc voltage and current for multifunction workload coverage, enabling calibration of data loggers, strip chart recorders, multimeters, and other industrial instruments
- Supports automation using MET/CAL® Plus Calibration Management Software or custom automated programs with standard RS-232-C and GPIB interface
- Eight user programmable setpoints allow quick recall of values for zero, span and linearity checks during calibration. Programmable setpoint dwell times for automated calibration and troubleshooting
- Programmable setpoint dwell times for automated calibration and troubleshooting
- Selectable internal or external CJC (cold junction compensation) provides you with the ability to make exacting thermocouple measurements using remote junctions
- Easy five-way binding posts for low-loss convenient hookup. Banana plug, screw terminal, spade lug, wraparound terminal, wire pass-through terminal
- NIST-traceable calibration with data is included
Specifications One Year (Source) | |||||
| Voltage (1 ma Max Load) |
| ||||
| Current (10V Compliance |
| ||||
| Resistance |
| ||||
| Thermocouple (B,C,E,J,K,L,N,R,S,T,U) |
| ||||
| Specifications One Year (Measure) | |||||
| SPRT 25.5 Ohm |
| ||||
| Resistance |
| ||||
| Thermocouple (B, C, E, J, K, L, N, R, S, T, U) |
| ||||
| RTD* |
| ||||
| Ni 120 |
| ||||
| Cu 10 |
| ||||
| YSI 400 thermistor |
| ||||
| General Specifications | |||||||
| Settling Time |
| ||||||
| Standard Interfaces |
| ||||||
| Temperature Performance |
| ||||||
| Temperature Coefficient |
| ||||||
| RH |
| ||||||
| Analog Low Isolation |
| ||||||
| EMC |
| ||||||
| Calibration Documentation | Report of calibration with data included; 17025 accredited report optional | ||||||
| Weight/Dimensions |
| ||||||
