201CNQ050PbF Schottky Diode Rectifier Module 200A 50V TO-244 Package for Power Supplies, Solar Inverters & Automotive Electronics
$48.95 $89
-45%
Delivery & Return:Free shipping on all orders over $50
Estimated Delivery:7-15 days international
People:16 people viewing this product right now!
Easy Returns:Enjoy hassle-free returns within 30 days!
Payment:Secure checkout
SKU:17177077
Guranteed safe checkout
Product Description
Vishay 201CNQ050PbF, Schottky Diode Rectifier Module, 200 Amp, 50V, TO-244 Package
Features
- Pressure Contact Technology
- Electrically insulated base plate
- Very low forward voltage drop
- Very low leakage current
- Planar passivated chips
- International standard package
- 2500V Isolation
- 20mm Base Width
Applications
- Power Supplies
- Rectifier for drives applications
- Uncontrolled Rectifiers
- Rectifiers for UPS
- Battery Chargers
- Filed Supply for DC Motors
- DC supply for PWM inverter
Specification
| Vishay Part Number | 201CNQ050PbF |
| Vrrm | 50V |
| Diode Configuration | Schottky Diode Rectifier - Common Cathode |
| IF(av) @ 125 Deg C (50% Duty) | 200 Amp per device, 100 Amp per leg |
| Package Size | W:20mm L:93mm D:16.5mm |
| Itsm | 16 kA |
| VF(to) | 0.67 -> 0.81V |
| Tj(max) | 175°C |
| rF | Not Published |
| Terminals | 1/4"-20UNC |
| Hole Centres | 80mm (M6) |
| Gate Terminals | N/A |
| R th(j-c) | 0.19°C/W |
| R th(c-h) | 0.10°C/W |
| Weight | 68g |
| Mounting Torque | 40 Nm (40 Nm Terminals) |
| Factory Pack Qty | 10 |
| Certification | UL Listed, ROHS |
| Vishay Headquarters | Germany |
Datasheet
