7.5 KVAR Single Phase Power Factor Correction Capacitor - 440V, 50Hz, 124.2uF, 65x148mm with Discharge Resistor - Ideal for Industrial Motors, HVAC Systems & Energy Efficiency Applications
$87.45 $159
-45%
Delivery & Return:Free shipping on all orders over $50
Estimated Delivery:7-15 days international
People:8 people viewing this product right now!
Easy Returns:Enjoy hassle-free returns within 30 days!
Payment:Secure checkout
SKU:80997080
Guranteed safe checkout
Product Description
276.066-512410/221302, Power Factor Correction Capacitor, Single Phase, 7.5 KVAR, 124.2uF, 440V, 50HZ, 65 x 148mm, Requires Discharge Resistor
Characteristics and utility
- 7.5 kVar @ 440V @ 50 Hz, 124.2uF
- Discharge resistors required (sold seperately)
- Reactive power factor correction
- Nitrogen Gas Filled
- Connector type - single sided terminal
- Indoor mounting
Safety
- Overpressure disconnection system
- Protection by internal fuses
Construction and materials
- Low losses metallized self-healing polypropylene film, high density, high temperature and greater dielectric resistance Volt/µ
- Polyurethane self-extinguishing resin V0, developed under standard UL 94 by RTR Energía
- Aluminium case with bottom fixing M12x16
Standards
- IEC 60831-1/2
- EN 60831-1/2
Specification
| Electronicon Part Number | 276.066-512410/221302 |
| Technology | Nitrogen Gas Filled, Low Loss, Self Healing |
| Dimensions | 65 x 148mm |
| Standards | IEC 60831-1/2, EN 60831-1/2 |
| Voltage | 440V @ 50Hz |
| Kvar | 7.5 Kvar |
| Capacitance | 124.2uF |
| Tolerance On Capacitance | -5% + 10% |
| Imax | 22 Amp |
| Overpressure Disconnection System | YES |
| Self Extinguishing Resin | YES |
| Internal Fuses | YES |
| DWCAP system (Patented) internal windings Displacement | YES |
| Mounting | M12 x 16mm (Indoor) |
| Operating Temperature Range | 50°C Max, 30°C Mean(1 year), 40°C Mean(24 hrs) |
| Lifetime | 120,000 Hours |
| Termination Style | Filter Type Terminal |
| Unit Weight | 1.2kg |
| Factory Pack Quantity | 25 |
