ATO CUS DC20000 4000 420U Hall Effect Current Transducer - 0-4000A Range, 4-20mA Output, 24VDC Power Supply - Ideal for Industrial Automation, Energy Monitoring, and Power Distribution Systems
$818.95 $1489
-45%
Delivery & Return:Free shipping on all orders over $50
Estimated Delivery:7-15 days international
People:30 people viewing this product right now!
Easy Returns:Enjoy hassle-free returns within 30 days!
Payment:Secure checkout
SKU:88657947
Guranteed safe checkout
Product Description
ATO-CUS-DC20000-4000-420U, O/L Hall Effect Current Transducer, 0-4000A, 4-20mA Instant Output, +24VDC Supply
For the electronic measurement of currents: DC, AC, pulsed, mixed, with a galvanic isolation between the primary circuit (high power) and the secondary circuit (electronic circuit).
Features
- Insant output versions 4-20mA, 0-20mA, 0-10V, 0-5V output
- Hall effect measuring principle
- Galvanic isolation between primary and secondary circuit
- Instantaneous voltage output
- Isolation voltage 2.5kV Rms /50 Hz /1min
- Low power consumption
- Package in ABS
- Instantaneous voltage or current output options
Advantages
- Easy installation
- Small size and space savings
- Only one design for wide current ratings range
- High immunity against external interference
Applications
- Battery supplied applications
- Uninterruptible Power Supplies (UPS)
- Power supplies for welding and telecom applications
Application domain
- Industrial
- Traction
Specification
| LEM Part Number | ATO-CUS-DC20000-4000-420U |
| Technology | Open Loop Hall Effect |
| ROHS | Yes |
| Supply Voltage | +24VDC |
| Load Current (RMS + DC) | 4000 Amp |
| Overload Rating | N/A |
| Output | 4-20 mA Instantaneous |
| Isolation | 2.5kV (AC, 50Hz, 1 min) |
| Bandwidth | DC Only |
| Mounting Style | Busbar or Panel Mount |
| Operating Temperature Range | -25°C / 85°C |
| Accuracy | 1% |
| Termination Style | F2023A (FUJICON) |
| Unit Weight | 6kg |
| Factory Pack Qty | 2 |
