4.3" HMI Touch Screen Panel with Millenium 3 Cable - 24VDC RS485 Modbus RTU Interface for Industrial Automation & Control Systems | Essential Series CT104 (Model 88970523) | Perfect for PLC Monitoring, Factory Equipment, and Process Control Applications
$393.8 $716
-45%
Delivery & Return:Free shipping on all orders over $50
Estimated Delivery:7-15 days international
People:6 people viewing this product right now!
Easy Returns:Enjoy hassle-free returns within 30 days!
Payment:Secure checkout
SKU:31171070
Guranteed safe checkout
Product Description
Crouzet Essential Series CT104, 4.3" HMI Touch Screen(88970524) with Millenium 3 Cable(88970505), 24VDC, RS485 Modbus RTU
Specification
| Crouzet Part Number | 88970524 (CT104) + 88970524 |
| Function | Human Machine Interface (Touch Screen) + HMI Connection Cable |
| Nominal Voltage | 24VDC (19.2 - 28.8VDC) @ 300mA |
| Display Size | 4.3" |
| Resolution | 480 x 272 |
| Brightness | 400 cd/m² |
| Storage Memory | 128MByte |
| RAM Memory | 128MByte |
| USB | Host USB 2.0 |
| Ethernet | N/A |
| Port RS232 | COM1 Male |
| Port RS485 | COM1 2/4 wires Male, COM3 2 wires Male |
| Voltage Resistance | 500VAC (1 Min) |
| Dimensions | 128 x 102 x 32 mm / 5.04 x 4.02 x 1.26” |
| Real Time Clock | 5 Years with CR2032 Battery |
| Termination Style | Screw |
| Weight | 250g |
| Certification | CE |
| Factory Pack Qty | 1 |
| Over Voltage Category | 3 in accordance with IEC/EN 60664-1 |
| Pollution Degree | 2 in accordance with IEC/EN 61131-2 |
| Protection rating | IP40 (Front), IP20 (Rear) |
| Mechanical Resistance | Immunity to vibrations IEC/EN 60068-2-6, test Fc Immunity to shock IEC/EN 60068-2-27, test Ea |
| Resistance to HF Interference | Immunity to radiated electrostatic fields IEC/EN 61000-4-3 Immunity to fast transients (burst immunity) IEC/EN 61000-4-4, level 3 Immunity to shock waves IEC/EN 61000-4-5 Radio frequency in common mode IEC/EN 61000-4-6, level 3 Voltage dips and breaks (AC) IEC/EN 61000-4-11 Immunity to damped oscillatory waves IEC/EN 61000-4-12 |
| Conducted and radiated emissions | Class B (*) in accordance with EN 55022, EN 55011 (CISPR22, CISPR11) group 1 (*) Except configuration (88 970 1.1 or 88 970 1.2) + (88 970 250 or 88 970 270) + 88 970 241 class A (class B in a metal enclosure) |
| Operating Temperature | -20 →+70 °C except CB and XB versions in VDC : -30 →+70 °C (+40 °C in a non-ventilated enclosure) in accordance with IEC/EN 60068-2-1 and IEC/EN 60068-22 |
Datasheet
Software
Compatibility
Built in Communications driver compatible with Millenium 3, Millenium EVO, and EM4 PLC's. See our for Pricing and Specification
